Building Permit Drawings
Welcome to GranDesign Engineering—your reliable partner for building permit and structural engineering services across Ontario. We help homeowners, builders, and property owners prepare the documents required for permit applications, so projects move forward faster and with fewer surprises.
From home additions and basement renovations to interior alterations and new builds, we provide clear, code-aligned drawings and professional guidance from the early design stage to permit submission. Many of our clients are located in the Durham Region, including Whitby, Oshawa, and Ajax, but we also support projects across the Greater Toronto Area and surrounding municipalities.
Why Building Permits Matter
Building permits are not just paperwork—they protect you. Permits help ensure your project is designed and built to meet the Ontario Building Code, zoning rules, and safety requirements. Skipping a permit can lead to stop-work orders, legal issues, costly delays, and even removal of completed work.
Our role is to make the process easier by preparing permit-ready drawings and structural documentation that municipal reviewers can approve with confidence.
When a Building Permit Is Required (Common Ontario Projects)
You may need a permit for interior renovations and construction work such as:
- finishing an unfinished space (for example, a basement)
- adding or removing walls
- structural changes (beams, load-bearing walls, foundation modifications)
- changing insulation type or value in exterior walls
- adding or changing plumbing (including installing a fixture where a rough-in exists)
- changing the use of a space
- adding to the existing building footprint
- creating a second unit (including many legal basement suite projects)
Note: Building additions must meet zoning requirements, including setbacks, lot coverage, and height limits.
Our Building Permit & Engineering Services
We support residential and commercial projects with the drawings and details typically required for permits and approvals.
1) Building Permit Drawings (Ontario)
We prepare complete building permit drawing packages tailored to your project type and the municipality’s submission standards. Our goal is to create clear documentation that reduces revisions and speeds up approvals.
2) Structural Engineering & Structural Details
If your project includes load-bearing changes, openings, additions, or foundation modifications, we provide structural design, calculations (when needed), and construction details that align with code and real-world buildability.
3) Permit Support for Home Additions
Planning a second-story addition, rear/side extension, attached garage, carport, sunroom, porch enclosure, or a deck above typical height limits? We prepare drawings and structural details to support permit applications and help ensure your addition is safe and compliant.
4) Basement Permits & Basement Renovations
Basement projects often require permits—especially when you add walls, bedrooms, bathrooms, plumbing, or create a legal second unit. We support:
- basement finishing (living space, guest room, rec room)
- legal basement apartment / secondary suite drawings
- walkout basement work (where applicable)
- plumbing/heating modifications shown on drawings (as required)
- underpinning-related structural support (project-dependent)
5) Separate Entrance Permit Support
Adding a separate entrance can trigger multiple review items (structural, zoning, fire separation, and more). We help prepare the documentation needed for a smoother permit submission.
6) Interior Alteration Permits
Interior alterations often look simple—but permit requirements can be strict when structure is involved. We support projects such as:
- removing walls to create open-concept layouts
- adding or enlarging windows and doors
- installing new exterior doors
- enclosing an existing porch, patio, or deck
- layout changes that impact exits, stairs, or key building elements
7) New Home Design & Permit Drawings
For new homes, we can support the permit process with:
- new house design drawings
- structural and construction details
- coordination-ready documentation for project teams
- optional 3D modeling/visualization (if you offer it)
Areas We Serve (Ontario)
GranDesign Engineering supports building permit drawings and structural engineering across Ontario. Many clients are in the Greater Toronto Area and Durham Region—projects frequently come from Whitby, Oshawa, Ajax, Pickering, and Clarington, as well as other municipalities throughout the GTA and surrounding regions.
If your property is outside these areas, contact us—requirements are often similar across Ontario, and we can confirm what applies to your project.
FAQ
In Ontario, permits are commonly required for new construction, demolition, renovations that involve structure, additions, basement finishing (in many cases), changes to plumbing systems, changes to the use of a space, and projects that alter insulation values or key building components. Requirements vary by municipality and scope, but it’s safest to verify before starting work.
Permit fees vary based on project type, floor area, and municipality. The most accurate cost comes from the local building department’s fee schedule. We can help you understand what the municipality may classify your project as, so you can estimate more accurately.
Often, yes—especially if you are adding walls, bedrooms, bathrooms, plumbing, modifying structure, or creating a second unit. If your basement project includes structural work or new fixtures, a permit is typically required to confirm compliance and safety.
Ready to Start Your Permit Drawings?
If you’re planning a renovation, addition, basement project, or new build, we can help you prepare the drawings and structural documents needed for a strong permit application.
Contact GranDesign Engineering to discuss your project and next steps.
[grandesign_cities]
Our Services
From residential renovations to commercial permits, we provide P.Eng-stamped structural drawings and coordinated engineering support across the GTA.
Why our clients keep coming back.
All drawings stamped and certified by Professional Engineers of Ontario.
Over 30 years of experience in all categories of construction projects, from residential to commercial.
We know GTA municipalities well — that means faster reviews and fewer back-and-forth cycles.
Professional engineering services at competitive, transparent rates.
You’ll always know where things stand — we keep you updated throughout.
Every municipality has its own quirks. We know them so you don’t have to learn the hard way.
Additional Coordinated Services
We coordinate supporting documents when they apply to your permit scope.
If your open-concept project is part of a larger renovation that requires additional documents, we can coordinate them so the package stays consistent.
Where We Work
We prepare building permit drawings across the Greater Toronto Area and Durham Region. Each municipality publishes its own submission checklist and applies its own zoning by-law, so we build the package to match the city you are applying to. Select your municipality below for local requirements.
Build Your Future With GranDesign.
Partner with us for structured permits, seamless approvals, and engineering built to last. Tell us about your project and we’ll walk you through exactly what your municipality needs.Request a Quote
Tell us about your project — we typically respond within one business day.
Building Permit FAQs
Do I need a building permit in Ontario?
Most work that affects structure, layout, exits or plumbing requires a permit — additions, second storeys, basement apartments, load-bearing wall removal, decks above a set height, garages and commercial fit-outs among them. Cosmetic work such as painting, flooring or replacing cabinets generally does not. Send us your scope and we will confirm what your municipality requires at no charge.
What drawings are needed for a building permit?
A typical submission includes a site plan, existing and proposed floor plans, elevations, building sections, and structural drawings covering beams, lintels, framing and foundations. Depending on scope your municipality may also request energy efficiency compliance, grading, mechanical information or a current survey.
Do I need an engineer or a BCIN designer?
It depends on the size and classification of the building and the nature of the work. Many residential projects can be submitted by a qualified BCIN designer, while structural elements and larger buildings require a licensed professional engineer. We provide both in-house and confirm which applies before drawings begin.
How long does a building permit take in Ontario?
Review times are set by each municipality and vary with workload, project type and how complete the submission is. What we control is the quality of the package — a complete, coordinated set that answers the plan examiner’s questions on the first pass is what avoids repeated review cycles.
What happens if the city returns comments on my application?
Review comments are normal. We interpret the plan examiner’s notes, revise the drawings, prepare any additional documentation requested and resubmit. You are not left to translate review language on your own.
Can you help if work was already done without a permit?
Yes. We assess what was built, prepare drawings documenting the as-built condition, and identify what is required for a retroactive permit, including any remedial work. This is a common situation and it is usually resolvable.
Which municipalities do you work in?
We prepare permit drawings across the Greater Toronto Area and Durham Region, including Whitby, Oshawa, Ajax, Pickering, Toronto, Markham, Vaughan, Newmarket and Kawartha Lakes, and regularly take on projects in surrounding Ontario municipalities.
How do I get a quote for building permit drawings?
Call us or send the quote form on this page with your address, a description of the work, and any sketches, surveys or existing drawings you have. We review it and reply with a free, no-obligation quote and an outline of what your submission will need.
